Parameter Specification
Shearing Length 2500 mm
Max Capacity (Mild Steel) 4 mm
Max Capacity (Stainless Steel) 2.0 mm – 2.5 mm
Cutting Angle 1° 30′ (Fixed or Adjustable depending on model)
Strokes Per Minute (SPM) 18 – 22 SPM
Backgauge Travel 20 mm – 600 mm (Motorized)
Throat Depth 100 mm – 150 mm (Standard)
Main Motor Power 5.5 kW (7.5 HP)
Hydraulic Hold Downs ~10 – 12 Cylinders
Dimensions (L x W x H) Approx. 3100 x 1600 x 1600 mm
Approx. Weight 3,000 kg – 3,500 kg
