1000mm – Between centres
360mm – Swing over the bed.
335mm – Spindle bore.
Swing over bed : 360 MM
Swing in gap bed : 502 MM
swing over cross slide : 223 MM
Distance between centers : 1000 MM
Bed Width : 187 MM
Bed Height : 290 MM
Spindle Bore : 38 MM
Spindle Speed : 70 – 2000 rpm
Cross slide travel : 160 MM
Compound slide travel : 95MM
leadscrew Diameter : 22 MM
Imperial threads : 4 – 56 TPI
Metric thread : 0.4 – 7 MM
Tail stock Quill & diameter : 32MM MT3
Cutting tools ( Max ) : 16 x 16 MM
Main Motor : 1.5 kw
Voltage 220
Weight : 950 kg’s
Dimensions : 1600 x 760 x 780 mm
R 60, 000.00 Excl Vat.
