Feature Metric Imperial (Approx)
Nominal Force 630 kN (63 Tons) 63 Tons
Stroke Length Adjustable (10 – 100 mm) 0.4″ – 4″
Strokes Per Minute 50 – 70 SPM
Shut Height (Max) 260 – 300 mm 10″ – 12″
Ram Adjustment 70 – 80 mm ~3″
Table Size (Bolster) 710 x 480 mm 28″ x 19″
Throat Depth 250 – 260 mm ~10″
Hole in Bed Ø 150 – 200 mm Ø 6″ – 8″
Motor Power 5.5 kW 7.5 HP
Machine Weight ~4,200 – 4,500 kg ~9,500 lbs
Inclinable Angle Max 25°
