Capacity:

Max. Swing diameter: 580mm

Max. turning diameter: 330mm

Max. turning length: 1000mm

Distance between centres: 1100mm

Travel:

X-axis: 185mm

Z-axis: 940mm

Spindle:

Max speed: 3000rpm

Spindle Nose: A2-8

Bar capacity: 75mr

Turret: (Optional)

Type: 12 Station

OD Tool: 25mm

ID Tool: Ø 32mm

Feed Rate:

X-axis: 15m/min

Z-axis: 15m/min

Hydraulic Tailstock: (Optional)

Quill diameter: 75mm

Quill taper: MT#4

Travel: 900mm

Quill travel: 80mm

Machine Dimensions:

Machine weight 5400kgs

L x W x H 3400x2300x1900 mm

Price: R700 000 excl
