Feature Metric Imperial (Approx)
Rated Force (Capacity) 100 Tons (1,000 kN) 100 Tons
Stroke Length (Adjustable) 10 – 125 mm 0.4″ – 5″
Table Size 1000 x 640 mm 39.3″ x 25″
Ram (Slide) Area 800 x 475 mm 31.5″ x 18.7″
Throat Depth 355 mm 14″
Shut Height (Max) 380 mm 15″
Slide Adjustment 90 mm 3.5″
Strokes Per Minute 75 – 150 SPM
Main Motor Power 7.5 kW – 11 kW ~10 – 15 HP
Machine Weight ~10,600 kg ~23,300 lbs
Dimensions (L x W x H) 1725 x 2230 x 2970 mm
