Table size 1450 x 400mm

Table T Slot 18mm x 3mm x 100mm

Maximum Table load 200Kg’s

Table travel (X, Y, Z) 900mm / 450mm / 500mm

Distance between Spindle nose and Table 50 – 550mm

Spindle type and diameter BT40 / 120mm

Spindle servo motor 7.5Kw

Spindle speed 8000Rpm

Maximum Tool diameter 80mm

Maximum Tool length – weight 200mm / 7Kg’s

Tool Changing time (arm type) 1.6sn

Rapid feed (X, Y, Z) 15 / 15 / 12mt / min

Cutting speed 8mt / min

Weight 3000Kg’s

Tool Changer Umbrella Type
